    Positive Displacement Cast Iron Roots Type Air Blower For Ash Blowing In Power Plant

    Ask Lasest Price
    Brand Name : BK
    Model Number : BK6008
    Certification : ISO9001 / ISO14001/CE
    Price :
    Payment Terms : L/C, T/T
    Supply Ability : 150 sets / month
    Delivery Time : 30 working days after receiving advance payment
    • Product Details
    • Company Profile

    Positive Displacement Cast Iron Roots Type Air Blower For Ash Blowing In Power Plant


    Positive displacement cast iron Roots blower for ash blowing in power plant


    1. Company brief


    By advanced production & test equipment, technology and management method introduced from abroad, by


    advanced management software, B-Tohin Machine ( Jaingsu ) Co.,Ltd. is committed to the production of high


    efficient and energy-saving blowers. And it's our sincere wish that we supply high-quality products and good service.



    2. Performance Parameters Sheet of BK6008


    ModelBK6008
    Air capacity6.49-20.01m3/min
    Discharge differential pressure10-80KPA
    Rotary speed850-1800rpm
    Motor type3-22KW
    380/400/415/440V/220V, 3PHASES, 50/60HZ, frequencytype
    Motor brandStandard: Siemens Beide or Wannan motor
    Siemens and ABB motor for your option
    Installation typeStandard: horizontal type

    *For different installation type and materials, please feel free to contact us.


    ModelPort Dia (MM)SpeedInlet airflow (m3/min)and shaft power(KW)
    0.1kgf/cm20.2kgf/cm20.3kgf/cm20.4kgf/cm20.5kgf/cm20.6kgf/cm20.7kgf/cm20.8kgf/cm2
    1000mmH2O2000mmH2O3000mmH2O4000mmH2O5000mmH2O6000mmH2O7000mmH2O8000mmH2O
    0.01Mpa0.02Mpa0.03Mpa0.04Mpa0.05Mpa0.06Mpa0.07Mpa0.08Mpa
    rpmm3/minKWm3/minKWm3/minKWm3/minKWm3/minKWm3/minKWm3/minKWm3/minKW
    BK6008125 (5")8508.662.548.044.497.566.037.167.596.819.406.4911.21
    100010.452.999.835.289.357.108.958.938.6011.068.2813.197.9814.817.7216.85
    115012.243.4411.626.0711.148.1610.7410.2710.3912.7210.0715.179.7717.039.5119.37
    125013.443.7412.826.6012.348.8711.9311.1611.5913.8211.2616.4910.9718.5110.7021.06
    140015.234.1914.617.3914.139.9413.7212.5013.3815.4813.0618.4612.7620.7312.4923.59
    150016.424.4915.807.9215.3310.6514.9213.4014.5716.5914.2519.7813.9522.2213.6925.27
    165018.224.9417.598.7217.1211.7116.7114.7416.3618.2516.0421.7615.7424.4415.4827.80
    180020.015.3919.399.5118.9112.7818.5016.0818.1619.9117.8323.7417.5426.6617.2730.32

    3. Structure Drawings



    1) Working smoothly as helical timing gears is adopted.

    2) It is flexible mounting ways because of the same structure in inlet and outlet.

    3) It adopts more reasonable bearing structure, which can increase the bearing operation life.

    4) It is low noise, vibration and energy consumption.


    Optional accessories and equipment


    Blower enclosure
