100 Kpa 20m3/Min 6" 55 Kw Cast Iron Mini Roots Blower Three Lobe

B-Tohin Machine (Jiangsu) Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap 100 Kpa 20m3/Min 6" 55 Kw Cast Iron Mini Roots Blower Three Lobe from wholesalers

    Buy cheap 100 Kpa 20m3/Min 6" 55 Kw Cast Iron Mini Roots Blower Three Lobe from wholesalers
    • Buy cheap 100 Kpa 20m3/Min 6" 55 Kw Cast Iron Mini Roots Blower Three Lobe from wholesalers
    • Buy cheap 100 Kpa 20m3/Min 6" 55 Kw Cast Iron Mini Roots Blower Three Lobe from wholesalers

    100 Kpa 20m3/Min 6" 55 Kw Cast Iron Mini Roots Blower Three Lobe

    Ask Lasest Price
    Brand Name : BK
    Model Number : BKW7011
    Certification : ISO9001/ISO14001/CE
    Price : Negotiation
    Payment Terms : L/C, T/T
    Supply Ability : 50 SETS per month
    Delivery Time : 5 to 20 working days, depends on order amount and specification
    • Product Details
    • Company Profile

    100 Kpa 20m3/Min 6" 55 Kw Cast Iron Mini Roots Blower Three Lobe


    Water Treatment Roots Rotary Lobe Blower, high pressure 100KPA air compressor

    BKW blower can be used for various industries, such as for separating small particles and algae in groundwater, recovering valuable products in industrial sewage and so on. It can reach the air capacity of 3900 m3/h under 80KPA rising pressure.



    Specifications

    Model

    BKW7011

    Discharge bore sizeDN150 (6")

    Air capacity

    20m3/min

    Discharge differential pressure

    100KPA

    Rotary speed

    1250rpm

    Cooling water volume

    10 l/min

    Motor type

    55KW
    380/400/415/440V, 3PHASES, 50/60HZ

    Installation type

    Standard: horizontal type.
    Vertical type available for your option

    N.W. of main blower body

    790kg



    Features


    1. Integral-shaft ductile iron impellers
    2. Large size of cylindrical roller bearings
    3. Hardened teeth face for precision helical timing gear

    4. Tri-lobe rotor with optimized curve
    5. Flexible installation ways available



    Parameter sheet

    ModelPort Dia (MM)SpeedInlet airflow (m3/min)and shaft power(KW)(m3/min)
    0.6kgf/cm20.7kgf/cm20.8kgf/cm20.9kgf/cm21.0kgf/cm2Cooling
    Water
    6000mmH2O7000mmH2O8000mmH2O9000mmH2O10000mmH2O
    0.06Mpa0.07Mpa0.08Mpa0.09Mpa0.1Mpa
    rpmm3/minKWm3/minKWm3/minKWm3/minKWm3/minKWL/min
    BKW7011150 (6")70010.1417.489.7218.62      10
    85013.4021.2212.9922.6012.6225.7612.2729.0411.9232.20
    100016.6624.9616.2526.5915.8830.3015.5334.1715.1837.88
    115019.9228.7119.5130.5819.1434.8518.7939.2918.4443.56
    125022.1031.2121.6933.2421.3237.8820.9742.7120.6247.35
    140025.3634.9524.9537.2324.5842.4224.2347.8423.8853.03
    150027.5437.4527.1239.8926.7545.4526.4151.2526.0656.82


    Structure of blower main body

    100 Kpa 20m3/Min 6" 55 Kw Cast Iron Mini Roots Blower Three Lobe


    Flow direction of cooling water




    Available accessories for your choice

    1. inlet silencer (with air filter)
    2. outlet silencer
    3. relieve valve
    4. check valve
    5. flexible joint
    6. pressure gauge
    7. blower pulley and motor pulley
    8. V-belt
    9. belt cover
    10. public base
    11. motor

    12. control cabinet

    13. acoustic enclosure
